SPECIFICATIONS

ATV: Quad bikes

Brake Type: Park In Transmission and Hand Brake

Displacement: 1000cc

Drive Mode: Shaft drive

Drive System Type: Selectable 2WD 4WD Lock 4WD with Visco-4Lok front Differential

Engine: 4 Stroke V Twin SOHC

Engine Capacity: 801-1100cc

Engine Type: 4 Stroke V Twin SOHC

Front Suspension: Arched double A-arm with front sway bar

Maximum Speed: 100KM H

Name: All-terrain vehicles

Overall Vehicle Size (L x W x H): 2450*1290*1500mm

Person Capacity: 2

Rear Suspension: Torsional Trailing arm Independent (TTI)

Starting system: Electric

Wheel Size: F 28 9 14 R 28 11 14

is_customized: Yes



New Style 4wd Atv Quad Bike Electric Start CF Moto 1000cc Utv 4x4 Force Shaft Drive Gas ATV



Technical Parameter
Engine & Drivetrain
Cooling		Liquid
Cylinders Displacement		976cc
Drive System Type		Selectable 2WD / 4WD / Lock 4WD with Visco-4Lok front Differential
Engine Type		4-Stroke V-Twin，SOHC
Bore*Stroke		91x75
MAX.Torgue		95NM/5500RPM
MAX.Horsepower		92HP/7300RPM
Starting system		Electric
Transmission		CVT shaft
Fuel System/Battery		BOSCH Electronic Fuel Injection
Transmission/Final Drive		Automatic CVT P/R/N/L/H
Dimensions
Rack Capacity		75/150 LBS
Estimated Dry Weight		1,014 lb (460 kg)
Fuel Capacity		4.8 Gallons
Ground Clearance		13 in. (33 cm)
Overall Vehicle Size(L x W x H)		2450*1290*1500mm
Payload Capacity		740 lb (336 kg)
Person Capacity		2
Wheelbase		59 in. (1493 mm)
Seat Height		36.75 in. (93.3 cm)
Brakes
Front/Rear Brakes		Dual 260 mm disc brakes with hydraulic twin-piston calipers
Parking Brake		Park In-Transmission and Hand Brake
Additional Specifications
Front Suspension		Arched double A-arm with front sway bar
Instrumentation		Digital Gauge, Speedometer, Odometer, Tripmeter, Tachometer, Coolant Temperature, Volt Meter, Hour Meter, Service Indicator, Clock, Gear Indicator, Fuel Gauge, Hi-Temp Light, Seatbelt Reminder Light, DC Outlet
Lighting		White LED Low/High & Red LED Tail / Brake Lights
Rear Suspension		Torsional Trailing arm Independent (TTI)
Tires / Wheels
Electronic Power Steering		Standard
Front Tires		28 x 9-14
Rear Tires		28 x 11-14
Wheels		Cast Aluminum
Choose your favorite color: Red ,Blue ,Green ,Orange ,Yellow ,white ,Black ,Grey

1. [Global Terrain Capability] Unafraid of regional restrictions

•

Deep-tread off-road tires + 30cm ground clearance: Easily handles muddy countryside roads, gravel, grasslands and soft sand deserts without any bumps

•

Two-wheel drive/four-wheel drive switchable + differential lock (premium model): Stable climbing up to 30° slopes, no slipping on slippery roads, compatible with 90% of unpaved roads worldwide

•

Waterproof and sealed design: Operates smoothly in light rain and flooded roads. Snow tires are available for winter use on icy and snowy roads, making it suitable for all seasons

2. [Easy to Use] Easily controlled.

•

Compact body (2-2.5m long): Turning radius less than 3m, nimbly navigating narrow forest roads and farm roads

•

Motorcycle-style handlebar steering + Automatic transmission: No complicated shifting required, with electronic power steering (standard on entry-level models), making it easy for women and elderly users to operate.



•



Four-wheel stability: More rollover-resistant than ordinary motorcycles, reducing driving risks and meeting safety requirements.



3. [Multi-Scenario Essentials] Dual-Purpose Work + Recreation





•



Outdoor Work Essential: Front and rear trailer hooks can tow up to 500kg, suitable for farm plows and orchard transporters. Add a cargo bed and it instantly becomes a "mountain truck."



•



Off-road Entertainment Hit: Desert bashing, grassland galloping, and off-road park racing.



•



Emergency Rescue Suitable: Suitable for transporting supplies to remote areas and forest fire patrols filling the gap in large vehicles and also suitable for public welfare applications.





4. [Easy Maintenance] Reduce after-sales costs.







•



High-strength steel tube frame: Impact-resistant and resistant to jolts, with a normal use of 5-10 Reduce maintenance frequency.



•



Simple Mechanical Structure: The engine and transmission have a low failure rate. Daily maintenance requires only oil changes and brake checks, which users can perform independently, without the need for a professional technician.



•



Global Accessories: Core components (tires, oil, brake pads) are universally compatible and easily sourced, ensuring convenient after-sales service.



5. [High Cost-Effectiveness] purchasing is more cost-effective.





•



Fuel-Efficient: 500-1000cc engines offer fuel consumption of 8-12L/100km, 30% more fuel-efficient than comparable SUVs.







6. [Customizable Modifications] Meet diverse needs.





•



Functional Modifications: Add a snowplow (for snow removal), a winch (for self-rescue/rescue), GPS navigation (for remote areas), and an LED Spotlights (Night Operation)



•



Flexible Exterior Customization: Supports vehicle wraps and color changes, and offers accessories such as bumpers, luggage racks, and speakers to suit diverse aesthetics.



•



Multiple Specifications Available: From the entry-level 500cc model to the high-end 1000cc model, prices cover the mid-range, low-end, and high-end markets.
